Steps involved in Deep Well System:
-
Well Drilling
-
Installation of Well Casing
-
Control Panel
-
Pumping & Commissioning
Deep Well Point System
The deep well system is also a versatile predrainage dewatering system which can pump high and low volumes of groundwater. This method is best suited to homogeneous aquifers that extend well below the bottom of the excavation. Deep well systems consist of one or more individual wells, each of which has its own submersible pump at the bottom of the well.
Deep well systems are suitable for watertable or confined aquifers and will lower the water table 100 feet or more in a single lift without staging.
We offer effective and innovative turn-key solutions to groundwater control problems using Deep Wells. We offer a full professional service from initial design, drilling, supply and installation of pumping equipment together with all associated appurtenances.
Advantages:
-
Ability to penetrate strata impervious to the jetting method of wellpoint systems.
-
Installation of up to 100 feet deep or more in a single stage.
-
Capable of pumping tens to thousands of gallons per minute per well.
-
Deep Wells can be effective when placed outside of the jobsite work area.
-
Deep well dewatering systems are used when large volumes of groundwater must be pumped, highly permeable soils result in rapid recharging of the aquifer, and/or the depth of excavation excludes other dewatering methods.
